Name: PELLET DUO 95 boiler, 330K BTU
Brand: TIS SP. Z.O.O.
SKU: BOILER-PELLET-95
Price: 10348.0 USD
Availability: InStock

PELLET DUO 95 boiler, 330K BTU

People watching this item right now

92% EFFICIENCY PELLET BOILER WITH EXTENDED AUTONOMY UP TO 2 WEEKS Pellet Duo is optimized for burning pellets. The boiler includes a self-igniter burner. You can burn pellets, corn, flax, sunflower husks, grains, cherry pits or... Read more

Description

92% EFFICIENCY PELLET BOILER WITH EXTENDED AUTONOMY UP TO 2 WEEKS

Pellet Duo is optimized for burning pellets. The boiler includes a self-igniter burner. You can burn pellets, corn, flax, sunflower husks, grains, cherry pits or manual feed biomass.

Heat: 12000 ft²
Weight 1'720 lb, Width 60 1/2'', Depth 44'', Height 66''
Manual Firebox: 56 gal, maximum logs length 48"
Automatic Hopper: 185 gal - 880 lb of pellets
Made in Europe
Commercial Grade for Commercial Use

Pellet Duo is our most modern and efficient automatic boiler. The fuel supply operates with a hopper, a motorized auger and a motorized burner feeder with integrated fuel backdraft protection. The burner is made of heat-resistant stainless steel, a self-igniter, flame sensor, moving grates system for cleaning up ashes and the fan. The optimize combustion result in complete heat recovery with a guaranteed efficiency of 92%.

European Standards of Emissions EN 303-5:2012

TIS tronic 496p master the combustion process depending on user parameter, weather, exhaust sensor and fuel quality. The controller easily adapt to any modern hydronic heating system and combine with domestic hot water, thermal storage, direct feeding, zone mixing design and more. Simply enter the setpoint heating water temperature and the boiler will modulate the combustion to match load. If there is no load the boiler will standby and reignites when needed. The automation with the large capacity hopper provides 4 to 10 days autonomy. The controller also includes functions of circulation pumps, motorize mixing valve, buffer tank, fuel level, summer/winter mode and thermostat feedback.

Pellet Duo is manufactured with the finest certified boiler steel ASTM A106. The wide door openings make easy cleaning of the top heat exchanger, middle loading of biomass and removal of ashes from the bottom. All maintenance is performed from the front and there is no need to unscrew anything else. High-quality multi-layer coating, non-combustible 2" insulation, and thermal protection systems ensure long-term and trouble-free operation.

Its hopper, made of durable zinc steel, is easy to assemble on-site, ensuring a seamless installation process. Trust this high-quality boiler to provide warmth and convenience all winter long.

Warranty: 10 years

Best used with: Boiler Station: All-in-one Solution, provides a circulation pump, a thermometer, a Boiler Protection Valve, and Insulation

Reviews

Pellet 95

We had an issue with our old wood boiler G3 from Pollar Furnaces. I made the phone call. Talked with Allan. All I can say is wow. They are professionals. I had a couple questions talked with their knowledgeable service team. Received the boiler and hopper spent a day getting it in place. Spent a day hooking it up. The unit works flawlessly. I would recommend this boiler to everyone. My wife and I are very very happy with the unit. Easy to maintain. If you had a gasification wood boiler you know how much maintenance it took to keep that going. This unit once a week to do a quick clean out. 20 minutes. Not like the other ones 8 hours. It’s great not having to go out and refill every 8-10 hours. The unit keeps our 10,000 sq ft home with two forced airs units and in floor heat throughout the house. This unit has no problem keeping up. Once we build a shop we will attach to the boiler as well. It won’t have any issues keeping up to everything. Take it from me I’m a journeyman plumber, this unit is epic……. Well worth the money. I smile every morning and every evening not having to go out and reload the boiler.

Pellet Boiler Farm House

Pellet 95 serves my farmhouse of 10'000 square feet and still has much capacity more. The large hopper gives me a week to 2 weeks of autonomy. Made in Switzerland burner. Great Heavy Duty Boiler and Great Support!

Pellet 95 Boiler

The unit is great. Used it to heat a 30x96 greenhouse. Phillip is a great guy. He know the machine well. His customer service is great. Technical knowledge is great. I would recommend mbtek pellet boilers if you are in the maket for a boiler.

Duo 95

The boiler works well and was everything I expected if I had a complaint it would only be set up instruction in multiple languages and more in detail. Other than that great unit heats my 4000 square feet of house and our swimming pool.

Pro 11 wood boiler

Haven’t had a chance to install this boiler but unpacked it and very pleased with the manufacturing quality of the system. When I get it installed I’ll send another review

Looking good

Product arrived well packed, and undamaged.
Customer service was great! Very helpful over the phone. looking forward to doing more business in the future.

Pellet DUO 50 boiler, 170K BTU.

Purchased this boiler specifically to heat a buffer tank in my shop which in turn heats hydronics in the concrete floors. Item took quite a while to ship about a month or so, ended up waiting the longest on the thermostatic mixing valve. These units are coming from Poland so I imagine a boat floats it over. The pellet hopper was not as pictured on the website and it has to be fully assembled. The sheet metal parts are accurate and of high quality that the hopper is made out of. The boiler was also well built and of high quality. The instructions were mediocre and translated from another language, there was a fair amount of head scratching, assumptions, and google translate. But it is manageable to work with. I purchased this unit as 220V and I assumed 60Hz, I was wrong. It is 220V but at 50Hz, which is okay as the boiler came with a 220V 50Hz power supply which has to be mounted separately and will need its own electric box. The part at MBtek that irritated me was I called their company in the U.S. Pennsylvania but my credit card was ran in Canada. My credit card company charged an extra 3% due to this foreign transaction fee basically $200 extra. I called Allen (Australian feller) at MBtek and he began with telling me they would credit me this amount, then I never heard back. I called again and he asked that I send my credit card statement to prove I was charged this fee and gave me a number to text a pic to, I did this also but never heard back, never got a credit. Poor customer service if you ask me, so consider yourself warned. I believe it is important to indicate to customers that your card will be ran in another country. Okay back to the boiler. To give you an idea of the costs here is what parts were for me based on me doing all the install for free, no labor. Boiler ($6000), Selkirk Chimney system ($2200), Piping ($1600), Elec ($800), Having a warm shop (priceless). So basically I have $10600 into this install took me about 2 weeks. My guess is you can double that number if you hire a contractor to install. At the end of the day I'm still pleased with the purchase and hope I get many years of service.

1-1/4 thermostatic boiler protection valve

Valve was easy to plumb in once I understood how it worked. Did not come with any kind of instructions, MBtek website has a diagram of how this worked. Basically, AB port goes to the boiler intake (mixed water), and the water exit (heated water) gets piped to B port this forms a loop until the mixing valve begins to open A port (cold water). This prevents the boiler from running to cold which can cause an acidic condensate from the pellets burning, which over time will eat your boiler from the inside out. Be sure to install this to protect your investment.

Seadona 1-1/4 circulator pump

Installed this pump with DUO Pellet boiler, it has different curves you can select for how you want it to operate. It was easy to wire into the controller. Runs on 220V 50Hz which is the same as what powers the boiler controller. I've only been running the pump for about a week now, so can't comment on longevity.
