APOLLO 8 Zone Valve Control
$315.91
- 8-Zone Centralized ControlEasily connect up to 8 thermostats, 8 actuators, and 1 pump.
- Designed in the USAPremium, CSA/UL certified all-in-one manifold wiring solution.
- Built-In Fuse ProtectionHighly reliable and safe design includes 3 spare fuses.
- Complete Plug-and-PlayIncludes a powerful 120VA transformer and a 15ft power cable.
- Smart LED MonitoringEfficiently monitor your open zones at a glance with bright LEDs.
Product details
APOLLO 8 Zone Valve Control
Zone control box for coordinating up to eight APOLLO actuators and thermostats from one centralized wiring point above the manifold.
Key Benefits
- Connects up to 8 zones with support for 8 actuators, 8 thermostats, and 1 pump
- Centralizes manifold wiring for a cleaner and faster installation
- LED status display shows open zones at a glance
- Includes transformer and cable for straightforward setup
- Fuse protected with spare fuses included
- CSA / UL certified for added installation confidence
Specifications
- Power Supply: 120VAC input / 24VAC control
- Zone Capacity: 8 actuators + 8 thermostats + 1 pump
- Transformer: 5A transformer with 15 ft cable and US plug
- Control Transformer Rating: 120VA
- Installation: Mounted above the manifold to centralize connections
- Compatibility: APOLLO actuators and APOLLO thermostats
Customer Success Stories
Heats my home nicely and economically. The cold weather does not seem to affect the pump. Overall I'm very happy with the system. The techs have been very helpful whenever I have had questions regarding installation, etc.
Reliable Heating in Cold Weather
Economical performance that isn't affected by low temperatures.
Reliable Heating in Cold Weather
8-zone manifold wiring control
APOLLO 8 Zone Valve Control
-
Superior interoperability
Readily integrates with APOLLO actuators and thermostats for centralized zone control.
-
Neat, dead-simple wiring
Installs above the manifold to centralize wiring connections and simplify system organization.
-
8-zone expansion
Connect up to 8 zone actuators, 8 thermostats, and 1 pump from a single control center.
-
Real-time monitoring
LED indication provides quick visibility into open zones and live operating status.
-
CSA/UL certified
Certified design helps support safe, compliant installation and dependable operation.
-
Installer-ready package
Includes a 5A transformer, 15-foot power cable, and US plugs for straightforward setup.
Centralized zoning control
Bring thermostats, actuators, and pump control into one organized hub so manifold wiring stays cleaner and easier to manage.
Fast monitoring
The onboard LED display gives quick feedback on active zones, helping installers and homeowners confirm operation at a glance.
Built for APOLLO compatibility
Designed to work directly with APOLLO thermostats and actuators, reducing guesswork when assembling a complete zoning package.
Confident installation
CSA/UL certification plus the included transformer and long power cable support a simpler install path with fewer extra parts.
Technical specifications
Centralized 24VDC control box for APOLLO radiant zoning, designed to manage up to 8 loops with thermostat, actuator, and pump connections in one organized manifold control point.
| Power Supply | 24VDC, 50/60Hz, 10A |
|---|---|
| Passive Output (Boiler) | 5A |
| Circulating Pump Output | 24VDC, 5A |
| No Power Linkage | 1 normally open (common terminal) |
| Number of Circuits | 8 loops |
| Max Number of Actuators in a Circuit | 8 pcs |
| Output Delay | 200s |
| Included Power Hardware | 5A transformer with 15ft cable and US plugs |
Use a family-specific bottom-tabs section later if this product needs comparison tables, grouped specs, or product-handle logic.
Technical & user manuals
This documentation covers installation, wiring, operation, and maintenance topics for the APOLLO 8 Zone Valve Control. For additional support, contact MBTEK.
APOLLO 8 Zone Valve Control - Installation Manual
Manual covering installation, wiring, and operating guidance for the APOLLO 8 Zone Valve Control.
