3 - Controller terminal
4 -Â Connecting line of controller
5 -Â DC frequency converter 25 A, 220VAC 1PH
6 -Â Outlet water temperature sensor
7-Â Electronic expansion valve, main valveÂ
8 -Â FAN motor
9 -Â Water flow switch
Display Touchscreen Controller
Fan DC Motor
Drive Board
Carel Electric Control
Evaporator Assembly
Heat Exchanger Assembly
Four-Way Valve
Main EEV
Economizer
Auxiliary EEV
Compressor
